Description
Faro Freestyle 2 Handheld Scanner, twice the capture efficiency and twice the versatility, fastest portable 3D scanner, scans can be completed in record time, delivers high-quality, colored, 3D data with up to 0.5mm accuracy.
Includes;
- (1X) FARO Freestyle 2 sensor
- (1X) Mobile PC
- (1X) High-speed USB stick
- (1X) Battery and Charger
- (1X) USB cable
- (1X) Targets kit
- (1X) Cleaning kit
- (1X) Quick guide
- (1X) Rugged case
- (1X) Belt and shoulder strap
- (1X) Onsite calibration plate
- (1X) Magnet kit for smartphone
Faro Freestyle 2 Handheld Scanner
Faro Freestyle 2 means twice the capture efficiency and twice the versatility
With Freestyle 2, one-hand operation means that even the most hard-to-reach locations inside and outside can now be scanned. And as the fastest portable 3D scanner on the market, scans can be completed in record time. Unmatched photorealism delivers high-quality, colored, 3D data with up to 0.5mm accuracy.
Real-Time Visualization
- Display lets you view what you capture as you scan
Wide-Range of Scanning Distances
- Captured 3D Points starts at 0.4m
- Can be set to a maximum of 10m
Capture in Variety of Lighting Conditions
- Designed for normally illuminated interiors and outdoors, including in overcast conditions
- Even provides usable data in complete darkness One-Hand Operation
- Lightweight with no bulky tablet or long cables
Guided Scanning
- Haptic feedback alerts operator when adjustments need to be made to the users scanning technique
- Proprietary tracking engine enables users to make natural movements while scanning
On-Site Compensation
- White-balancing, post-processing can be done at the scene
- No annual calibration required Integrated Training
- Live display of data quality with integrated training videos, and tutorials
Features
> Range: 0.4–5 m (up to 10 m with limited data quality)
> Identifiable features: up to 0.2 mm
> 3D point accuracy: = 0.5 mm
> Lighting conditions: Complete daylight, 10,000–45,000 lux (reduced output with direct Sunlight)
> Light source: Integrated LED flash
> Scan volume: 39.5 m³ at a maximum range of 5 m
> Acquisition rate: up to 220,000 points/s,the density of the point
> Exposure time: 0.1ms – 7ms (autoexposure)
> Texture color: 24 bit
> Dimensions: 285mm x 256mm x 130mm
> Connectivity: HDMI, USB 3.0, WiFi
> Weight: 1.48kg
> IP rating: IP 52
> Compensation: Onsite – with supplied compensation plate
> Operating temperature range: 0 – 40 °C
> Operating humidity range: Non-condensing
> Eye Safety: Class 1 Laser
> Wavelength: 798 – 816nm
Mobile Specifications
> Microsoft Windows 10 Pro, 64-Bit Intel Core i7
> 256 GB hard disc with 16 GB RAM
> HDMI; USB 3.0 ports; Wi-Fi
Field of Applications
> Architecture, Engineering & Construction (AEC)
> Facility management
> Documentation of interior
> Restoration & conservation
> Virtual Reality
> Oil & gas
> Forensics & law enforcement
> Accident reconstruction
